Bitumen Emulsion Sprayers
HYDROG SH PREMIUM
You can afford PREMIUM Class as well
SH PREMIUM is the highest and most prestigious class of HYDROG emulsion sprayers. It was created in response to the needs of the most demanding customers expecting the highest precision of emulsion dosing and uniformity of spraying, as well as for those who use their equipment intensively under extreme conditions. SH PREMIUM sprayers are characterized by an unparalleled in its price range performance quality, technical capabilities (e.g. the biggest spraying width and output range) as well as proven reliability.
Emulsion sprayers HYDROG SH PREMIUM meet rigorous requirements of investors for emulsion dosage per square meter and uniformity of emulsion surface coating – both in the execution of the so-called tack coats spraying and in the technology of road surface dressing
Spraying parameters
- Spraying bar hydraulically extended up to 5 m
- Equipped with a hand lance
- Spraying efficiency: from 0.10 to 2.55 kg/m2
- Automatic control of spraying performance depending on the sprayer speed
- Automatic cleaning of the spray bar after every spraying
Emulsion tank
- 3 000 – 5 000 – 6 000 – 8 000 – 10 000 – 12 000 l (depending on type)
- CLEAN PUMPING – system of non-filtered absorption of pure emulsion by the pump
- Filling by own pump or by top filling
Control and reports
- Intuitive desktop with colour 12” touch panel in the driver’s cab
- Automatic, intuitive control minimising the risk of operator mistakes (without manual valves)
- CCTV system for the bar during spraying
- Records of every spraying in memory with the possibility to print it out on an in-built printer
Emulsion heating system
- One of the most efficient systems available on the market
- Automatic maintenance of the emulsion operating temperature
- Supports internal power supply of AC 230 V 50 Hz
Emulsion pump
- Rotary displacement pump dedicated for bitumen emulsions
- EASY START system– automatic heating supporting the pump start-up
Components’ drive
- The Customer may choose from a PTO attachment or own Perkins diesel engine – 3-cylinder, liquid cooled with a power of 44 HP
Selected additional equipment
- Technical water tank with 140 l/min pump
- Lime slurry tank with spraying system
- Pressure washer for easier cleaning of the machine
- Additional heating systems
- Front brush – sweeper
Unique on the market, innovative solutions make SH PREMIUM class sprayers more environmentally friendly and economical. For example, when heating a full emulsion tank, the burner will consume about 10 litres less oil than other brands of machines. After spraying, the machine will automatically clean the pump and spray bars from emulsion residues.
